Waterproof Night Vision Smallest IR Universal Camera - Front or Back View

Waterproof Night Vision Smallest IR Universal Camera - Front or Back View

Waterproof Night Vision Smallest IR Universal Camera - Front or Back View 1. CMOS 2. Color image day & night 3. Effectiv
Basic Info
Model NO. C-253IR
Definition 420TVL
Chip CMOS
Waterproof Grade IP68
Night Vision Car Camera Back View or Front View
Waterproof Car Camera Front or Reversing Image
Transport Package Neutral Box
Origin China
HS Code 8525801390
Production Capacity 5000sets/Day
Product Description
Waterproof Night Vision Smallest IR Universal Camera - Front or Back View
1. CMOS
2. Color image day & night
3. Effective pixels: 640*480
4. CE
5. RoHs

Product Features:
1. Smart size for hidden installation.
2.1/4"CCD
3. Lens: 170 degrees
4. Waterproof and dust-proof (IP68) camera
5. With car reversing reference line(optional) camera.
6. Night vision available and high definition camera.
7. Day/Night sensor for automatic adjustment, minimum illumination auto fill light.

Installation Guides:
1. Fasten the camera by insert the hole drilled.
2. Connect the reverse lens switching lines;
3. Connect the camera's signal line to the signal extension line;
4. Connect the car's reverse light line to camera's video cable;
5. Check if all lines are correct connected and arranged;
6. Debug the working effects of the camera and the license light;
7. Cover the car trunk.
Finished.

Accessories:
1. AV cable 6 meters, DC cable 1.5 meter
2. User Manual
3. Holesaw

Technical Parameters:
Image Sensor 1/4" CCD
TV System NTSC/PAL
Sync System internal
Minimum illumination < 1 lux
White balance Auto
IR Lamps
Video color Colorful
Waterproof class IP68
Effective pixels 640(H)*480(V)
Resolution 420 TV lines
Sensing area 3.5964*2.7084mm
Video output 1.0Vp-p, 75Ω
Electronic shutter 1/60S-1/5000S
S/N ratio Better than 48dB
Lens angle 170 degree
Operation temperature -20° ~+70°
Storage temperature -30° ~+80°
Warranty 12 months

Packing Box(Universal):
