360 Degree Seamless Full Panoramic Birdview Monitoring Driving Assistant System

Basic Info

Model NO.	WMR-360-FS
Applicable Model	Car, SUV, Truck, Agricultural Vehicles, Engineering Vehicles, Sightseeing Car
Shell Material	ABS Plastic
Display Type	Without Screen
Interface	with BMW Pin
Function	Night Vision, Waterproof, Dustproof, Shockproof
Definition	420TVL
Chip	CMOS
Waterproof Grade	IP68
Upgrade	Via USB
Camera	4 Channels
Resolution	580*540p
Viewing Angle	180 Degree
Transport Package	Wemaer, or Neutral Box
Specification	ROHS/CE/E-Mark/FCC
Trademark	WEMAER, or Neutral
Origin	Guangzhou, China
HS Code	2850193000
Production Capacity	1, 00 000sets/Day

Product Description

360 Degree Around View Monitoring System (Standard Resolution)



Model : WMR-360-FS



1. Features:
1) 360 degree panoramic bird view with seamless splicing, without blind spots;
2) Easy and convenient, automatic calibration;
3) High definition input signal, with clear and fluent image quality;
4) Left and right turn signal real-time switching control panoramic profile picture;
5) Panoramic view displayed automatically during reversing;
6) Double light automatically control the panoramic view ON and OFF;
7) 4 way image real-time driving records, the local playback;
8) Video recording is activated by vibration, 3 minutes automatic recording;
9) Data recorder to SD card and U disk storage, max 32 GB storage supported;
10) Remote control for the panoramic switch, real-time video playback.



2. Specifications:

Item		Spec
Cameras	Image sensor	1/3" CMOS
	Lens Angle	180°
	Resolution	720x 480P
	SNR	>48dB
	Minimum illuminance	0.1 LUX
	Dynamic range	>72dB
	System	PAL/NTSC/AHD
	Video input	4-ch video input
	Output	Composite video signal
	Waterproof	IP68
Main Unit	Operating voltage	9~16V
	Operating current	<600mA
	Standby current	<5mA
	Operating humidity	40% ~ 80%
	Operating temperature	-20ºC ~ 70ºC

3. Accessories:

Main Box	1pcs
Car Camera (Left+Right+Front+Rear)	4pcs
Camera Extension Cable with Trigger Wire	4pcs
18mm Holesaw (for Side Camera Install)	1pcs
Wrench (for Side Camera View Angle Ajustment)	1pcs
Screws (for front and rear camera install)	4pcs
IR Remote Control	1pcs
IR Remote Receiver Extension Cable	1pcs
Video Output Cable with Monitor Trigger Wire	1pcs
Power Cable	1pcs

4. Installation:
